Top flue?Or Rear flue? It's up to you.
The Cleanest Wood burning stove weve ever built
Ancient Modern, A 21st Century stove built on 160 years' experience
A stove for the city. Approved for smoke control areas.
iron cast engineered to last
Enjoy the view!

Product Measurements
& Technical Specifications

175 woodburning stove dimensions
HETAS Cleaner Choice approved logo square

ESSE 175 F Technical Manuals

Download our manuals that are packed full of useful information to help you learn more about your ESSE product .
Can’t find the answer you’re looking for? Please contact us and we’ll be happy to help.

Download PDF Instruction Manual

Specifications
Energy Rated A+
Weight 97.5kg
Flue Outlet Top or Rear
Nominal Heat Output 5kW
Flue Pipe Diameter 5"
Particulate Reburn™ Technology Yes
Precision Burn™ Control Yes
Efficiency 83.7%
EcoDesign Ready Yes
DEFRA Exempt For Use in Smoke Control Areas Yes
Particulate emissions @ 13% O2 (mg/m3) 14
Clearances to combustibles
Sides 600mm (75mm with additional heat shield)
Top 450mm
Front 305mm
Rear 600mm (400mm with additional heatshield)
