Top flue?Or Rear flue? It's up to you.
Over 160 years' experience built into each & every ESSE stove
Ancient Modern, A 21st Century stove built on 160 years' experience
A stove for the city. Approved for smoke control areas.
Iron Cast Engineered to last

Product Measurements
& Technical Specifications

500 woodburning stove dimensions
HETAS Cleaner Choice approved logo square

ESSE 500 Technical Manuals & Parts

Download our manuals that are packed full of useful information to help you learn more about your ESSE product or browse available spare parts .
Can’t find the answer or part you’re looking for? Please contact us and we’ll be happy to help.

Download PDF Instruction Manual View available spare parts

Specification
Energy Rated A+
Efficiency 82.9%
Nominal Heat Output 5.0kW
Flue Pipe Diameter 5" (125mm)
Approved For Use On Decorative Hearths? Yes
Weight 51kg
Tertiary Air? Yes
EcoDesign Ready Yes
DEFRA Exempt For Use in Smoke Control Areas Yes
Particulate emissions @ 13% O2 (mg/m3) 19
Clearances To Combustibles
Sides 400mm
Top 450mm
Front 305mm
Rear 400mm
