Product Measurements
& Technical Specifications

705 woodburning stove dimensions
HETAS Cleaner Choice approved logo square

ESSE 705 Technical Manuals

Download our manuals that are packed full of useful information to help you learn more about your ESSE product .
Can’t find the answer you’re looking for? Please contact us and we’ll be happy to help.

Download PDF Instruction Manual

Specifications
Energy Rated A+
Weight 99kg
Flue Top or Rear
Heat Output 6-11kW
Fluepipe Diameter 6" (150mm)
Efficiency 76%
Additional Room Vent Ø62mm
EcoDesign Ready Yes
DEFRA Exempt For Use in Smoke Control Areas Yes
Particulate emissions @ 13% O2 (mg/m3) 33
Clearance to Combustibles
Sides 500mm
Top 450mm
Front 305mm
Rear 200 / 100mm with twin wall flue
