Product Measurements
& Technical Specifications

ESSE 1000 W Dimensions top and side hotplate



ESSE 1000 W Dimensions front and hetas cleaner choice approved logo

1000 W Technical Manuals

Download our manuals that are packed full of useful information to help you learn more about your ESSE product .
Can’t find the answer you’re looking for? Please contact us and we’ll be happy to help.

Download PDF Instruction Manual

Specifications
Energy Rated A
Weight 315kg
Flue Outlet Top Centre
Flue Pipe Diameter 6" (150mm)
1000 WN
Nominal Heat Output 4.6kW
Fuel 1.4kg p/hr
Efficiency 81.7%
Particulate Emissions @ 13% O2 (mg/m3) 20
1000 WD
Nominal Heat Output 7.6kW - 6.2kW to room / 1.4kW to water
Fuel 2.2kg p/hr
Efficiency 81.3%
Particulate Emissions @ 13% O2 (mg/m3) 40
Clearance to combustibles
Side wall below cooking level 20mm
Side wall at cooking level 100mm
Side wall above cooking level 200mm
Back wall 50mm
Floor in front of appliance 200mm
Front 1000mm
The appliance must be placed on a non-combustible floor
